ZGYX-430E430E-1

CELL PHONE
008613375052021
WHATSAPP
8613375052021
Collect
  • The product descript
  • Product parameters

1. The power of this type of drilling rig is standard Yuchai YC4A100 45KW and 55KW.

2. The maximum rotary torque of the selected machine can reach 5500N.m. It can be applied to anchor rod, heel pipe and large diameter twist drill pipe in foundation pit.

3. The walking part is equipped with four wheels and one belt of national standard construction machinery and plunger motor accelerator and decelerator system, which makes the drill more reliable and durable. The walking speed is increased to 3 km/h.

4. Independently developed high-performance wet air filtration, combined with dry air filtration, forms a three-stage air filtration system, which better protects the diesel engine. High efficiency dry double-click dust removal mechanism can be selected to make drilling basically dust-free. The environment of the mine site and the suction environment of the drilling engine have been improved, which meets the requirements of environmental protection.



linkman: Mr. Yang     Telephone:0086-594-2956555   Phone number:+8613375052021


QQ: 3473286593         WeChat/Skype/WhatsApp:+8613375052021
