ZGYX-421T

Product characteristics:

1. The matching power of the rig is Yuchai YC6A180Z, which is equipped with 10/14.5 screw machine. It is equipped with_60mm three-meter drill pipe and standard dry dust collector.

2. The drilling rig strengthens the strength of various structural parts and can fully withstand the functional requirements of the original ZGYX-420A drilling rig. Using cycloid motor to drive the rotary head reduces the failure rate and bulky volume of the original steel ball motor, at the same time greatly strengthens the torque of the drill, makes the drilling hole wider, the rotary shaft and excessive joints are directly connected by threads, and reduces the failure of the original seal leakage.

3. Large torsion adapts to a larger range of drilling aperture.

4. Promotion, lifting and switching are fast and slow to improve the efficiency of pole change.

5. The design of the new casing makes the maintenance and use of the drill very convenient, and enhances the beauty of the drill.

6. Equipped with dry and efficient dust collector device, drilling without dust, more environmentally friendly and energy-saving.

7. The standard plunger motor and the walking track of international construction machinery make the climbing more advantageous, the quality more reliable and the walking efficiency more efficient.

8. Standardized body leveling function makes the drilling rig more powerful in walking and cross-country performance.
